| Model | MI2.5 | MI2.6 | MI2.9 | MI3.9 |
| Pixel Pitch(mm) | 2.5 | 2.6 | 2.9 | 2.9 |
| Pixel Matrix Per Sq.m | 160,000 | 147,456 | 112,896 | 112,896 |
| Pixel Configuration | SMD1515 | SMD1515 | SMD1515 | SMD1515 |
| Brightness (cd/㎡) | 1000 | 1000 | 1000 | 1000 |
| Scan | 1/25 | 1/32 | 1/28 | 1/28 |
| Module Dimension | 250X250mm | 250X250mm | 250X250mm | 250X250mm |
| Cabinet Dimension | 500x500mm / 1.64x1.64ft | 500x500mm / 1.64x1.64ft | 500x500mm / 1.64x1.64ft | 500x500mm / 1.64x1.64ft |
| Cabinet Material | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum |
| Cabinet Weight | 7.5kg | 7.5kg | 7.5kg | 7.5kg |
| Power Con.(W/㎡) (Max / Avg) | 800W/200-300W | 800W/200-300W | 800W/200-300W | 800W/200-300W |
| Service Access | Full Front / Rear | Full Front / Rear | Full Front / Rear | Full Front / Rear |
| Refresh Rate (HZ) | 3840 | 3840 | 3840 | 3840 |
| Grey Scale (bit) | ≥16 | ≥16 | ≥16 | ≥16 |
| Viewing Angle (H/V) | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| IP Rate | IP43 | IP43 | IP43 | IP43 |
| Input Voltage (AC) | 110V / 240V | 110V / 240V | 110V / 240V | 110V / 240V |
| Model | MO2.6 | MO2.9 | MO3.9 | MO4.8 |
| Pixel Pitch(mm) | 2.6 | 2.9 | 3.9 | 4.8 |
| Pixel Matrix Per Sq.m | 147,456 | 112,896 | 65,536 | 43,264 |
| Pixel Configuration | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Brightness (cd/m2) | 4000 | 4000 | 4000 | 4000 |
| Scan | 1/32 | 1/21 | 1/16 | 1/13 |
| Module Dimension | 250X250mm | 250X250mm | 250X250mm | 250X250mm |
| Cabinet Dimension | 500x500mm / 1.64x1.64ft | 500x500mm / 1.64x1.64ft | 500x500mm / 1.64x1.64ft | 500x500mm / 1.64x1.64ft |
| Cabinet Material | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum |
| Cabinet Weight | 7.5kg | 7.5kg | 7.5kg | 7.5kg |
| Power Con.(W/m2) (Max / Avg) | 800W/200-300W | 800W/200-300W | 800W/200-300W | 800W/200-300W |
| Service Access | Full Front / Rear | Full Front / Rear | Full Front / Rear | Full Front / Rear |
| Refresh Rate (HZ) | 3840 | 3840 | 3840 | 3840 |
| Grey Scale (bit) | ≥16 | ≥16 | ≥16 | ≥16 |
| Viewing Angle (H/V) | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| IP Rate | IP65 | IP65 | IP65 | IP65 |
| Input Voltage (AC) | 110V / 240V | 110V / 240V | 110V / 240V | 110V / 240V |
