◆ 135'' | 2K and above ◆ SMD/GOB/HOB/COB Optional
◆ 27mm Thickness Screen ◆ 16bits, 3840Hz, 7000:1 Contrast
| Model | LFCPoster-0.9 | LFCPoster-1.2 | LFCPoster-1.5 |
| Pixel Pitch(mm) | 0.9375 | 1.25 | 1.56 |
| Pixel Matrix Per Sq.m | 1,137,778 | 640,000 | 409,600 |
| Pixel Configuration | COB | COB | COB |
| Brightness (cd/㎡) | 500 | 600 | 600 |
| Scan | 1/60 | 1/45 | 1/48 |
| Module Dimension (W*H) | 150*168.75mm / 0.49*0.55ft | ||
| Cabinet Dimension (W*H*D) | 600*337.5*27mm / 1.97*1.11*0.09ft | ||
| LFCPoster Dimension (W*H) | 135'' | 3,000*1,687.5mm / 9.84*5.54ft | ||
| LFCPoster Resolution | 3,200*1,800 | ||
| Outer Frame Size (W*H*D) | 1804*1948*770mm / 5.92*6.39*2.53ft (Fold down) | ||
| Outer Frame Size (W*H*D) | 3010*2598*770mm / 9.88*8.52*2.53ft (Unfold and lift) | ||
| Power Consumption (Max / Avg) | Max 5000W/㎡ / Avg 1500W/㎡ | ||
| Cabinet Material | Die Casting Aluminum | ||
| Cabinet Weight | 4.5KG | ||
| Contrast Ratio | 7000:01:00 | ||
| Service Access | Front | ||
| Refresh Rate (HZ) | ≥3840 | ||
| Grey Scale (bit) | 16 | ||
| Viewing Angle (H/V) | 170°/170° | ||
| IP Rate | Front IP65 / Rear IP43 | ||
| Operation Temperature | -20℃ ~ +60℃ | ||
| Input Voltage (AC) | 110V / 220V | ||
