| Model | L Pro/F Pro 2.6 | L Pro/F Pro 2.9 | L Pro/F Pro 3.9 | L Pro/F Pro 4.8 |
| Pixel Pitch(mm) | 2.6 | 2.98 | 3.91 | 4.81 |
| Pixel Matrix Per Sq.m | 147,456 | 112,896 | 65,536 | 43,264 |
| Pixel Configuration | SMD1515/1415 | SMD2121/1415 | SMD2121/1921 | SMD2121/1921 |
| Brightness (cd/㎡) | 1000/4000 | 1000/4000 | 1000/4000 | 1000/4000 |
| Scan | 1/32 | 1/21 | 1/16 | 1/13 |
| Module Dimension | 250×500mm | 250×500mm | 250×500mm | 250×500mm |
| Cabinet Dimension | L Pro -- 500x500mmF Pro -- 500x1000mm | L Pro -- 500x500mmF Pro -- 500x1000mm | L Pro -- 500x500mmF Pro -- 500x1000mm | L Pro -- 500x500mmF Pro -- 500x1000mm |
| Cabinet Material | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum |
| Cabinet Weight | L Pro -- 8KGF Pro -- 14KG | L Pro -- 8KGF Pro -- 14KG | L Pro -- 8KGF Pro -- 14KG | L Pro -- 8KGF Pro -- 14KG |
| Power Con.(W/㎡) (Max / Avg) | 800W/200-300W | 800W/200-300W | 800W/200-300W | 800W/200-300W |
| Service Access | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| Refresh Rate (HZ) | ≥3840 | ≥3840 | ≥3840 | ≥3840 |
| Grey Scale (bit) | ≥16 | ≥16 | ≥16 | ≥16 |
| Viewing Angle (H/V) | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| IP Rate | IP43 / IP65 | IP43 / IP65 | IP43 / IP65 | IP43 / IP65 |
| Input Voltage (AC) | 110V / 240V | 110V / 240V | 110V / 240V | 110V / 240V |
